FatCat 4000

Safety

  • 400L of Foam added inside Hulls - Unsinkable

  • High Freeboard

  • Self Draining Cockpit with Large Scuppers

  • Wide Side Decks

  • Flat Floor - no trip hazards

  • Stable - keep you balance

  • Multiple Grab Handles

Space

  • Wide Beam

  • Wide, unencumbered Sole (Floor)

  • Wide Side Decks for Comfort

  • Catamaran Design - Box Shape rather than wedge shape - uses full dimensions

  • Large Boarding Platform

  • Large amount of storage relative to boat size

  • Hulls have enough volume and stability to take increased payload

Stability

  • Catamaran Design

  • Wide Beam

  • Self Draining Cockpit/Large Scuppers remove any water fast

  • Very little bow lift at all speeds

Personalise Your Boat

A base FatCat 4000 comes with 4 x Grab Handles, 4 x Rod Holders, Transom Reinforcement, Anchor Locker & Lid, Fwd Locker Lips, Plywood floor with grip paint, Foam grip to side decks, Scuppers & Fuel Tank tie down points. From this base, we will work with you to create the boat to suit your needs and budget. Options include:

BOAT LAYOUT:   Open  I  Seats  I  Consoles

BOAT USE:  Recreational  I  Commercial

BOAT OPTIONS:  Windscreen I Bimini I Boarding Ladder I Fusion Stereo I Ski Arch I Tiller Extension I Additional

Rod Holders I Additional Grab Handles I Fishfinder I Lifting Lugs I Alloy Construction Option



ENGINE POWER:   15hp  I  20hp I  25hp  I  30hp  I  40hp

ENGINE TYPE:   2 Stroke  I  4 Stroke  I  Electric

ENGINE BRAND:  Parsun I Mercury I Evinrude I Honda I Yamaha I Suzuki I Tohatsu I Torqeedo

MAX ENGINE WEIGHT: 80Kg

​

TRAILER:  Extendable Drawbar  I  Drop Down Spare Tyre

​

SAFETY:  Navigation Lights I Anchor Light I Paddles

​

ADDITIONAL: Anything is possible within the confines of the platform - please contact us.

​

FINANCE AVAILABLE:

WE CAN SUPPLY ANY MOTOR FROM ANY BRAND INCLUDING:

Specifications

Hull Length (excl. Outboard): 3.8m

Beam (Width): 1.95m

Draft (Depth): 0.25m

Hull Weight: 240kg (plus extras)

Hull & Engine: 295kg (plus extras)

Hull & Engine on Trailer: 470kg (plus extras)

Total Length on Trailer: 5.1m

​

​

Construction: Rotomolded Polymer

Recommended Power: 15hp - 40hp

Max Outboard Weight: 80kg

Shaft Length: 20" (Long)

Fuel Tank Capacity (Std): 24L

Max Load: TBA

CE Category: TBA

​
